The worm gear units, IRS series remains one the best solution for simple applications in need of high ratios. This gearbox unit also propose perfect assistance for situation in which backstop needs to be strong and resistant.

Product Advantages

• Strong and resistant cast iron housing
• High ratios for low output speeds
• Low vibration
• Multiple mounting positions

Type	Torque (max.)	Shaft Diameter
İRSD-64	425 Nm	Ø 24
İRSD-81	825 Nm	Ø 30
İRSD-101	1465 Nm	Ø 40
İRSD-126	2650 Nm	Ø 50
İRSD-161	4820 Nm	Ø 70

Speed range
16,82 d/d…473,21 d/d

Applicable motor power
0,09 kW…11Kw

Input options
Motorsuz giris mili Motorlu



IRSDM (Foot mounted, Motor) IRSDFM (Flange Motor)	IRSD (Foot mounted) IRSDF (Flange)
